Ceramic Steel-shelled Silicon Carbide SiC Wear-resistant Pipe

Ceramic steel shell silicon carbide (SiC) wear-resistant pipe is a high-performance wear-resistant pipe. It combines the high hardness and wear resistance of silicon carbide ceramic with the high strength and good toughness of a metal steel shell, and is widely used in industrial fields.
Send Inquiry
Ceramic Steel Pipe SiC Special Ceramic Liner

In many industrial sectors, piping systems face harsh operating environments, with frequent problems such as wear and corrosion, severely impacting pipeline life and system stability. Ceramic steel pipes lined with SiC special ceramics, with their superior performance, are an ideal solution to these problems, revolutionizing industrial piping applications.
Send Inquiry
Sintered Silicon Carbide (SSIC) Ceramic Pump Spindle And Bushing Industrial Ceramic Pressing Target

Sintered silicon carbide (SSiC) ceramics offer excellent properties such as high hardness, wear resistance, and corrosion resistance. They are widely used in ceramic pump spindles and bushings, as well as industrial ceramic pressing targets.
Send Inquiry
Steel Back 99% SiC Ceramic Pipe

Steel-backed 99% SiC ceramic pipe is a composite wear-resistant pipe with a high-purity silicon carbide ceramic inner lining and a steel outer backing. It combines the high hardness and wear resistance of silicon carbide ceramic with the high strength and toughness of steel, offering excellent overall performance.
Send Inquiry
Ceramic Steel Composite Pipe Abrasion Resistant Armored Tube

The outer layer of ceramic-steel composite wear-resistant armored pipe is steel pipe, and the inner layer is corundum ceramic. The corundum layer has a Vickers hardness of 1100-1500, equivalent to tungsten-cobalt cemented carbide, and a Mohs hardness of 9, second only to diamond and silicon carbide, making it the hardest of all oxides. The outer steel pipe provides excellent toughness and strength, making the pipe both wear-resistant and impact-resistant.
Send Inquiry
Armored Ceramic Ring Pipe DN100-DN800 For Mining Slurry

Armored ceramic ring pipe typically features a composite structure consisting of a ceramic inner lining and a metal outer layer. The inner lining is typically made of corundum ceramic (Al₂O₃), which offers high hardness, high wear resistance, and excellent corrosion resistance, with a Mohs hardness of up to 9.0, equivalent to HRC90 or higher. The outer layer is a steel pipe, providing high strength and excellent toughness, ensuring the overall strength and impact resistance of the pipe. The two...
Send Inquiry
High Quality Alumina Ceramic Liner Tube Armored Wear-resistant Ceramic

High-purity alumina ceramic lining: Typically, 92%, 95%, or 99% pure alumina ceramics are used, such as Jingcheng Special Ceramics' K95 alumina ceramic. It boasts a hardness of HRA85 or higher, a density ≥3.8g/cm³, a compressive strength ≥1200MPa, and excellent wear resistance, with a volumetric wear rate ≤0.03cm³/(kg・m). Armored Structure Design: Armored wear-resistant ceramics are typically constructed by firing a ceramic tube as a whole and then pouring it into a steel pipe with a specialize...
Send Inquiry
Alumina Special Industrial Ceramic Wear-resistant Pipe For Lithium Battery Powder Conveying

Alumina lithium battery powder conveying industrial ceramic wear-resistant pipes are high-performance pipes designed for conveying powder materials during lithium battery production. They offer numerous advantages, detailed below: Performance Features · High Wear Resistance: Lined with high-purity alumina ceramic, achieving a hardness exceeding HRA90, this pipe offers far superior wear resistance to ordinary steel pipes. It effectively withstands the high-speed impact of lithium battery powders,...
Send Inquiry
Hot Sale Wear-resistant Alumina Ceramic Liner Pipe For The Lithium Battery Industry

Performance Characteristics The lithium battery industry's hot-selling wear-resistant alumina ceramic lined pipe uses a high-purity alumina ceramic lining with a hardness of over HRA90. Its wear resistance far exceeds that of ordinary steel pipes, and it can effectively cope with the high-speed erosion of lithium battery powder materials, reducing the frequency of pipe replacement by 90%. Strong Corrosion Resistance: The ceramic layer is chemically stable and resistant to 99% of acids, alkali...
Send Inquiry
Alumina Ceramic Liner Tube Wear-resistant Industrial Ceramic Pipe

Alumina ceramic-lined pipe is a composite industrial pipe. By combining an alumina ceramic layer with a metal base, it combines the high wear resistance of ceramic with the impact resistance of metal. The following is an analysis of its core characteristics and applications:
Send Inquiry
High-temperature Alumina Ceramic Linings Ceramic Lined Pipe

High-temperature alumina ceramic-lined pipes are composite pipes with a high-temperature sintered alumina ceramic lining and a metal (typically carbon steel or alloy steel) outer layer. Their core advantage lies in their ability to maintain excellent wear resistance, corrosion resistance, and structural stability even under high-temperature conditions. They are widely used in high-temperature material transportation applications in industries such as power, metallurgy, and chemicals.
Send Inquiry
High Quality Alumina Ceramic Liner Tube wear-resistant Industrial Ceramic Pipe

High-quality alumina ceramic-lined pipe is a composite pipe with a high-purity alumina ceramic lining, bonded to a metal pipe base through a specific process. Its structure generally consists of an outer layer of a metal pipe with a certain strength and toughness, such as Q235B, Q355B carbon steel, or stainless steel, and an inner layer of a wear-resistant and corrosion-resistant alumina ceramic. The thickness of the ceramic layer is determined by specific application requirements.
Send Inquiry
High Alumina Ceramic Liner Tube Abrasion-resistant Industrial Ceramic Wear-Resistant Pipe

High-aluminum ceramic-liner tube is a composite, wear-resistant industrial pipe made by combining a high-purity alumina (Al₂O₃) ceramic layer with a metal base (such as carbon steel or stainless steel). Its typical structure includes: Ceramic lining layer: Alumina content ≥95%-99%, Mohs hardness 9, Vickers hardness HV1100-1400, and wear resistance over 20 times that of ordinary steel pipe.
Send Inquiry
High Alumina Ceramic Wear-resistant Pipe Industrial Ceramic Liner Tube

High-alumina ceramic wear-resistant pipe (industrial ceramic lined pipe) is a type of industrial wear-resistant pipe made by combining high-purity alumina ceramic with a metal matrix. It is widely used in high-wear and high-corrosion conditions.
Send Inquiry
Alumina Wear-resistant Tile-lined Pipe Ceramic Plates/Sheets Welding/Cutting/Bending Services Included

Alumina wear-resistant tile-lined pipes and ceramic plates/sheets are advanced solutions designed for industries that face extreme abrasion, corrosion, and high-temperature environments. By lining steel pipes and structural components with high-purity alumina ceramics, companies benefit from significantly extended service life, reduced maintenance costs, and improved efficiency.
Send Inquiry
Ceramic Patch Lined Pipe Mining Ceramic Mosaic Pipe

Ceramic patch lined pipe mining ceramic mosaic pipe is a composite pipe formed by attaching wear-resistant ceramic sheets to the inner wall of a steel pipe using a special adhesive. The ceramic sheets are typically made of high-aluminum ceramic, such as 95% alumina, which offers high hardness and wear resistance. The steel pipe, typically made of Q235 or Q355, provides strength and toughness.
Send Inquiry
Ceramic Mosaic Lined Pipe Abrasion Resistant Patch Pipe

Ceramic mosaic-lined pipe is a composite pipe with an outer steel layer, typically Q235, providing protection and support. Its thickness is generally 5-8mm. The inner layer consists of toughened, high-aluminum, wear-resistant ceramic sheets bonded to the metal substrate in a mosaic pattern. The spacing between the tiles meets technical standards, resulting in a smooth, flat, and non-flaking inner surface. Flange connections are specially treated to prevent wear.
Send Inquiry
Aumina Ceramic Tube Liner Pipe

Alumina ceramic has the advantages of super hardness, high wear-resisting,good corrosion resistance and electric insulation,resistant acid-base,high intensity, thermostable, high temperature tolerance,good insulation,high strength,precision process,high mechanical strength,good chemical stability. Good smoothness, mechanical seal good, polishing surface and so on. Feature: 1.High chemical etching resistance. 2.High temperature up to 1200°C 3.Resistant to sudden cold and hot, un-explosive...
Send Inquiry
